Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction & Decoration, Special Purpose Honed tubes are widely used in hydraulic cylinders, cylinders, hydraulic machinery, engineering machinery, petroleum machinery, agricultural machinery, filling machinery, mining machinery and other fields. The main features are: 1. It is mainly used to produce pneumatic or hydraulic components 2. For outer cylinder of oil cylinder 3. The honing process is adopted to meet the requirements of the inner hole of the cylinder tube 4. High precision and high finish, the finish can reach ra0.2-0.4um
1.Steel grade: ST52.3, 1020, CK45, 4140 , E355，4130, Stainless Steel 304/316, Duplex 2205, Alloy Steel etc.
2.ID: 15mm-1500mm
3.OD:18mm-1800mm
4.Length: max 16m
5.Straightness: 0.5/1000
6.Roughness(Ra): 0.2-0.4um
7.ToleranceEXT:DIN2391,DIN17175,DIN1629,ASTM519,ASTMA106,JISG3441,GB/T8163,GB/T3639,GB9948,GB/T5312 etc.
8.Tolerance INT: ISO H8
9.Surface treatment：galvanized
10.Tolerance：±7%
11.Oiled or unoiled：Slightly Oiled
12.Delivery date：22-30
13.Type: cold drawing, cold rolling, honed
14.Conservation: anti rust oiled inside and outside surface, plastic caps in both ends
15.Package: bundle with steel strip and knitting strip, or wooden case.
Steel Grade | Chemical composition % | |||||
C | Si | Mn | P | S | Al | |
≤ | ≥ | |||||
20# | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | 0.035 | 0.035 | / |
45# | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | 0.035 | 0.035 | / |
Q345B | ≤0.2 | ≤0.5 | 1.00-1.60 | 0.03 | 0.03 | / |
Q345D | ≤0.2 | ≤0.5 | 1.00-1.60 | 0.03 | 0.03 | 0.015 |
25Mn | 0.22-0.29 | 0.17-0.37 | 0.70-1.00 | 0.035 | 0.035 | / |
27SiMn | 0.24-0.32 | 1.10-1.40 | 1.10-1.40 | 0.035 | 0.035 | / |
ST52 | ≤0.22 | ≤0.55 | ≤1.6 | 0.025 | 0.025 | / |
SAE1026 | 0.22-0.28 | 0.15-0.35 | 0.60-0.90 | 0.04 | 0.05 | / |
