Product Description

Professional manufacturer of honed tube & chrome rod/bar/shaft, founded in 2004, one of biggest manufacturer in China. We make honed tubes, Honed steel tubing, Hydraulic cylinder tubes, Skived tubes, Bored tubes; Chrome plated piston rods, Chrome bars, Linear shaft, Hollow rods; Cold drawn tubes, Pre-hone tubes, Ready to hone tubes. Honed tube is produced using our "Suitable to Hone" Drawn Over Mandrel (DOM) and Cold Drawn Seamless (CDS). The honing process involves using abrasive polishing stones and abrasive paper to remove small amounts of material, to produce extremely precise ID dimensions and improved finishes.

email enquire now

Product Details

Common steel pipe specification table

Outside diameter(mm) 0.D	Inside diameter(mm) 1.D	weight(kg/m)	Outside diameter(mm) 0.D	Inside diameter(mm) 1.D	weight(kg/m)
40	32	3.55	108	90	21.97
48	32	7.89	110	90	24.66
48	40	4.34	114	90	30.18
50	40	5.55	107	100	8.93
55	40	8.79	108	100	10.26
55	50	3.24	110	100	12.95
57	50	4.62	110	100	18.47
60	50	6.78	120	100	27.13
65	50	10.63	121	100	28.61
70	50	14.8	127	100	37.79
70	60	8.01	120	110	14.18
70	63	5.74	121	110	15.67
73	63	8.38	127	110	24.84
76	63	11.14	133	110	34.46
78	63	13.04	140	110	46.24
83	63	18.00	130	120	15.41
80	70	9.25	143	120	37.29
85	70	14.33	145	120	40.84
90	70	19.73	132	125	11.09
85	75	9.86	133	125	12.725
90	75	15.26	135	125	16.03
86	80	6.14	140	125	24.51
88	80	8.29	145	125	33.29
90	80	10.48	145	125	35.09
95	80	16.8	152	125	46.11
100	80	22.19	159	125	59.53
102	80	24.68	168	125	77.67
108	80	32.45	152	130	38.25
100	90	11.71	159	130	51.67
152	140	21.60	299	250
159	140	35.02	300	280
166	140	49.05	325	280
168	140	53.17	320	300
160	150	19.11	351	300
168	150	35.29	340	320
180	150	61.03	377	320
168	160	16.18	380	360
170	160	20.34	370	350
172	160	24.56	420	400
180	160	41.92	440	420
184	160	50.9	470	450
194	160	74.20	530	500
194	180	32.28	630	600
216	180	87.89	510	420
219	180	95.93	550	420
235	180	140.72	600	570
213	200	33.10	620	580
216	200	41.03	720	600
219	200	49.08	400	350
235	200	93.86	480	360
245	200	123.45	460	400
270	220	151.04	377	345
273	220	161.02	426	380
273	240	104.37	550	450
266	250	50.90	590	600
267	250	54.18	850	700
270	250	64.12	1000	800
273	250	74.16	1200	1000
Note: If you need special specifications, please consult online customer service customization

Product Details

Size	Outer Dia:21.3mm-660mm,According to customer requirements
	Wall Thickness:0.5mm-20mm,According to customer requirements
	Length:1-12m,According to customer requirements
Standard	GB12771-91, ASTM A1053/A1053M-06, ASTM A268/A268M-05A, ASTM A269-07,etc
	ASTM A270-03A, ASTM A312/A312M-06, ASTM A358/A358M-05, ASTM A632-04,etc
	ASTM A789/A789M-05b, ASTM A790/A790M-05b, ASTM A872/A872M-07A,etc
Material	10#,20#,45#,Q235,Q345,Q195,Q215,Q345C,Q345A,etc
Packing	Standard Seaworthy Package,according to customer requirements
Application	Medical equipment,Table wares,Construction,Kitchen utensils,Chemical industry,etc

Applications

Factory direct supply cold drawn seamless honing tube/pipe ck45 st52 for building
